12 FIBER OPTIC CABLE

Name: 12 FIBER OPTIC CABLE
Brand: SYNERGY TELECOM PVT. LTD.
Price: 20 INR
Availability: InStock

20 INR/Pair

Get a Price/Quote

Product Details:

Product Type 12 Core Fiber Optic Cable
Material Core: Glass optical fiber; Sheath: PVC/LSZH; Armor: Steel tape or none
Usage Telecommunication networks, data centers, LAN/WAN, industrial and CCTV applications
Function High-speed data transmission through optical fibers
Application Indoor or Outdoor armored/unarmored installations for network connectivity
Finish UV resistant, LSZH (Low Smoke Zero Halogen) outer sheath
Power Passive component (no direct power required)
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

12 FIBER OPTIC CABLE Price And Quantity

Price Range 20.00 - 25.00 INR/Pair
Price 20 INR/Pair
Minimum Order Quantity 10000 Meter

12 FIBER OPTIC CABLE Product Specifications

Application Indoor or Outdoor armored/unarmored installations for network connectivity
Weight Approx. 60-120 kg/km depending on construction
Power Passive component (no direct power required)
Usage Telecommunication networks, data centers, LAN/WAN, industrial and CCTV applications
Product Type 12 Core Fiber Optic Cable
Material Core: Glass optical fiber; Sheath: PVC/LSZH; Armor: Steel tape or none
Voltage Non-conductive; Not applicable (fiber optic cables do not carry voltage)
Size Core count: 12; Cable diameter: 7-9 mm (typical)
Function High-speed data transmission through optical fibers
Finish UV resistant, LSZH (Low Smoke Zero Halogen) outer sheath
Tolerance 0.02 mm (fiber diameter tolerance)

Transmission Distance Up to 10 km (Single Mode); Up to 2 km (Multi Mode)
Pulling Strength 800-1500 N (depends on type, armored/unarmored)
Connector Compatibility Compatible with SC, LC, ST, FC connectors
Min. Bending Radius 10x cable diameter (during installation); 20x (static)
Fiber Type Single Mode (OS2) or Multi Mode (OM1/OM2/OM3/OM4/OM5)
Jacket Color Usually Yellow (Single Mode), Orange/Aqua (Multi Mode)
Fiber Standard ITU-T G.652D for Single Mode; ISO/IEC 11801 for Multi Mode
Operating Temperature Range -20C to +70C
Attenuation 0.35 dB/km at 1310 nm (SM), 3.5 dB/km at 850 nm (MM)
Waterproofing Available with gel-filled or dry core for outdoor type

12 FIBER OPTIC CABLE Trade Information

FOB Port DELHI
Payment Terms Cash Against Delivery (CAD), Cash on Delivery (COD), Letter of Credit (L/C), Letter of Credit at Sight (Sight L/C), Telegraphic Transfer (T/T), Western Union, Paypal, Cash Advance (CA), Delivery Point (DP), Days after Acceptance (DA), Cash in Advance (CID), Cheque
Supply Ability 10000 Meter Per Month
Delivery Time Months
Packaging Details CUSTOMIZED PACKING
Main Export Market(s) Australia, North America, Eastern Europe, Western Europe, Africa, Central America, Middle East, South America, Asia
Main Domestic Market All India
Certifications Zebra antennas offer the high-performance and range needed for high traffic and precision. Zebra antennas offers the flexibility and performance required to meet the industry needs. Maximize Work Flow. Flexibility & Simplicity. Reliable Operation. Maximize Accuracy.

Product Description

1. Cables are water blocked and meet water penetration requirements of GR-20 CORE (this helps ensure that any damage to cable is restricted to a repairable length of several meters)

2. Outer jacket is moisture-resistant fungus-resistent and UV resistant for outdoor use

3. With a Riser rating, this cable can be used in all environments: Riser, general inside plant and outside plant

4. Tested to meet or exceed EIA/TIA 568-A/GR-409-CORE and ICEA-S-104-696

5. MSHA approve for mining applications

6. Compliant to Directive 2002/95/EC (RoHS)

Durability for Versatile Installations

This 12 Fiber Optic Cable is ideal for installations requiring both resilience and flexibility. It performs effectively in a wide temperature range (-20C to +70C) and offers high pulling strength (800-1500 N) for demanding installations. The UV-resistant, LSZH outer sheath ensures longevity and safety in both indoor and outdoor settings.

Wide Compatibility and Easy Integration

With compatibility with industry-standard connectors such as SC, LC, ST, and FC, the cable integrates seamlessly into existing network infrastructures. Designed for both armored and unarmored constructions, it is suitable for distributors, manufacturers, and traders seeking efficient networking solutions across India.

Reliable Performance and Safety

Adhering to strict international standards, this fiber optic cable provides low attenuation rates, superior bend radius management, and excellent waterproof options (gel-filled or dry core). Its core of precision glass optical fiber guarantees high-speed, error-free data transmission across telecommunication networks, surveillance systems, and data centers.

FAQs of 12 FIBER OPTIC CABLE:

Q: How does the 12 Fiber Optic Cable provide reliable network connectivity?

A: The cable utilizes high-quality single mode (OS2) or multi mode (OM1/OM2/OM3/OM4/OM5) optical fibers and robust construction materials to ensure reliable and high-speed data transmission, meeting ITU-T G.652D and ISO/IEC 11801 standards. Its low attenuation and strong pulling strength further contribute to stable performance.

Q: What types of environments are suitable for installing this fiber optic cable?

A: Designed for both indoor and outdoor installations, the cable can withstand operating temperatures from -20C to +70C. It is equipped with a UV-resistant and LSZH sheath for safety and durability, and is available in armored or unarmored forms to meet various installation requirements.

Q: When should I choose single mode versus multi mode fiber for my application?

A: Single mode cables (yellow jacket) are best for long-distance transmissions up to 10 km, typically used in wide area or backbone networks. Multi mode cables (orange/aqua jacket) are ideal for shorter links up to 2 km, such as in data centers or local area networks where high bandwidth over moderate distances is required.

Q: Where can this 12 Fiber Optic Cable be used effectively?

A: It is widely used in telecommunications networks, data centers, LAN/WAN setups, CCTV installations, and other industrial network applications throughout India. Its robust construction allows for indoor riser, plenum, and outdoor direct-burial installations.

Q: What is the process for installing this cable, and what precautions should be taken?

A: During installation, observe the minimum bending radius (10x cable diameter) and avoid exceeding the pulling strength (800-1500 N) to prevent damage. Make sure the cable is suited to the environment (armored or waterproof options for outdoors) and use compatible connectors such as SC, LC, ST, or FC for seamless integration.

Q: How does the cable benefit network operators and installers?

A: This cable offers high performance, flexibility, and safety features such as LSZH sheathing and UV resistance. Its compliance with international standards ensures interoperability and reliability, making it a practical choice for distributors, manufacturers, and systems integrators seeking quality solutions in the Indian market.
