2.92 Female to SSMP Female Flange Stainless Steel Floating adapter

2.92 Female to SSMP Female Flange Stainless Steel Floating adapter

Name: 2.92 Female to SSMP Female Flange Stainless Steel Floating adapter
Brand: SYNERGY TELECOM PVT. LTD.
Price: 4500.00 INR
Availability: InStock

4500.00 INR/Piece

Get a Price/Quote

Product Details:

Usage & Applications RF / Microwave High-Frequency Interconnect
Product Type 2.92 Female to SSMP Female Flange Floating Adapter
Material Stainless Steel Body, Beryllium Copper Contacts, PEI Insulator
Usage Precision signal transmission between 2.92 mm and SSMP interfaces
Function Provides low-loss, controlled impedance RF connection with flange floating alignment
Application RF Test Systems, 5G Equipment, Microwave Modules, Aerospace & Defense Systems
Finish Passivated Stainless Steel Body
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

2.92 Female to SSMP Female Flange Stainless Steel Floating adapter Price And Quantity

Price 4500.00 INR/Piece
Minimum Order Quantity 1 Piece

2.92 Female to SSMP Female Flange Stainless Steel Floating adapter Product Specifications

Application RF Test Systems, 5G Equipment, Microwave Modules, Aerospace & Defense Systems
Tolerance Precision RF Grade (Controlled 50 Impedance)
Material Stainless Steel Body, Beryllium Copper Contacts, PEI Insulator
Voltage 1000 V RMS (Dielectric Withstanding)
Usage & Applications RF / Microwave High-Frequency Interconnect
Usage Precision signal transmission between 2.92 mm and SSMP interfaces
Product Type 2.92 Female to SSMP Female Flange Floating Adapter
Finish Passivated Stainless Steel Body
Function Provides low-loss, controlled impedance RF connection with flange floating alignment
Size Approx. 1.00 0.65 0.50 in
Weight App 14 gram.
Power Low Power RF Signal Applications

2.92 Female to SSMP Female Flange Stainless Steel Floating adapter Trade Information

FOB Port NEW DELHI
Payment Terms Paypal, Cash Against Delivery (CAD), Cash on Delivery (COD), Cash Advance (CA), Cash in Advance (CID), Cheque, Days after Acceptance (DA), Delivery Point (DP), Letter of Credit at Sight (Sight L/C), Telegraphic Transfer (T/T), Western Union, Letter of Credit (L/C)
Supply Ability 1500 Piece Per Week
Delivery Time 2 Days
Sample Policy Free samples available with shipping and taxes paid by the buyer
Packaging Details As per Customer Requirements
Main Export Market(s) Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa
Main Domestic Market All India
Certifications ISRO, DRDO

Product Description

Electrical Requirements

Parameter	Specification
Frequency Range	0 40 GHz
Characteristic Impedance	50
VSWR	1.20:1
Insertion Loss	0.3 dB

Mechanical Requirements

Parameter	Specification
Durability (Mating Cycles)	500 cycles

Environmental Requirements

Parameter	Specification
Operating Temperature Range	-55C to +125C

Material Requirements

Connector Part	Material	Plating / Finish
Body	Stainless Steel	Passivated
Female Center Contacts	Beryllium Copper	Gold Plated
Insulators	PEI (Polyetherimide)
