3db Hybrid Coupler
1150 INR/Piece
Product Details:
X
3db Hybrid Coupler Price And Quantity
- 1150 INR/Piece
- 10 Piece
3db Hybrid Coupler Trade Information
- New Delhi
- Paypal, Telegraphic Transfer (T/T)
- 100 Piece Per Day
- 3 Days
- Yes
- Free samples available with shipping and taxes paid by the buyer
- As Required Buyer
- Western Europe, Africa, Central America, Eastern Europe, Australia, Middle East, South America, Asia, North America
- All India
Product Description
3db hybrid coupler
Specification
- Frequency Range (MHz ) 698 - 2700
- coupling(db) 10
- Insertion Loss(dB) .45
- In-Band Ripple 0.3
- VSWR 1.3
- Impedance 50 Ohms
- IMD (dBc) -140 @ +43dBm2
- Connectors N F
- Power Handling (Watts) 200
- Peak Power(W) 1000
- Temperature() -35+70
- Humidity 95%
- Environmental Specs indoor
High Performance at 6 GHz
The 3dB Hybrid Coupler is engineered for optimal functionality at 6 GHz frequency, making it ideal for wireless communication systems and microwave networks. Its compact design, combined with robust electrical specifications, ensures stable signal transmission and minimal loss across various connectivity solutions.
Versatile Application in RF Systems
With its standard 50-ohm impedance and ability to handle up to 50 watts, this hybrid coupler supports both splitting and combining signals efficiently. Its lightweight format allows for easy installation in radio transmitters, antenna feeds, and test instrumentation setups.
FAQs of 3db Hybrid Coupler:
Q: How does the 3dB Hybrid Coupler function in RF systems?
A: The 3dB Hybrid Coupler splits input signals into two outputs with equal amplitude but different phases, or combines two signals efficiently, optimizing performance in RF applications such as antenna networks and power distribution.Q: What are the key specifications of this hybrid coupler?
A: This coupler operates at 6 GHz, measures 152.4 mm, weighs 1 kg, supports up to 50 watts of current, and has a 50-ohm impedance, making it suitable for high-frequency communication systems.Q: When should I use a 3dB Hybrid Coupler in my setup?
A: This coupler is ideal for use whenever you need to split or combine RF signals with minimal loss, particularly in wireless communication networks, broadcasting stations, and testing environments.Q: Where is this 3dB Hybrid Coupler distributed and supplied?
A: The coupler is distributed and supplied through manufacturers, wholesalers, suppliers, and traders across India, ensuring broad market accessibility and support for diverse project requirements.Q: What is the installation process for the coupler?
A: Installation involves connecting the couplers input and output ports to your RF system components, ensuring alignment with the 50-ohm impedance for optimal performance. Proper mounting and securing are recommended due to its 1 kg weight.Q: How can this coupler benefit my application?
A: By using a 3dB Hybrid Coupler, you can achieve efficient signal management, reduced interference, and improved performance in radio frequency circuits, leading to enhanced communication quality and system reliability.Tell us about your requirement
