Product Description
Electrical
Characteristic Impedance 50 ohm
Frequency Range DC4 GHz
VSWR 115DC3 GHz
Dielectric Withstanding Voltage 1000V RMS50Hzat sea level
Dielectric Resistance 5000M
Contact Resistance Center Contact 1m
Outer Contact 025m
Durable Brass ConstructionConstructed from high-quality brass material, the BNC M RG 11 Crimp Connector offers long-lasting reliability and resistance to corrosion. Its superior build quality ensures consistent signal transmission, making it well-suited for demanding RF network environments often found in India.
Optimized for RF ApplicationsEngineered specifically for RF equipment, this connector supports a 50 Ohm impedance and up to 50 Watt power capacity. These characteristics make it highly efficient for minimizing signal loss and maintaining performance across professional RF network installations.
FAQs of BNC M RG 11 CRIMP CONNECTOR:
Q: How is the BNC M RG 11 Crimp Connector installed?
A: Installation involves crimping the connector onto an RG 11 coaxial cable using a suitable crimping tool. Careful preparation of the cable and precise positioning ensure a secure and reliable connection, vital for optimal RF performance.
Q: What advantages does this connector offer for RF networks?
A: The connectors 50 Ohm impedance and 50 Watt power rating make it ideal for high-frequency RF networks, reducing signal loss and supporting stable, clear transmission for demanding broadcast, communication, and instrumentation applications.
Q: When should I use a BNC M RG 11 Crimp Connector?
A: This connector is recommended when setting up or upgrading RF networks, particularly in situations requiring durable connectivity and efficient energy transfer. Its brass construction and specific design are suited for sustained operational use in professional environments.
Q: Where is this connector typically sourced in India?
A: You can find the BNC M RG 11 Crimp Connector through authorized distributors, manufacturers, suppliers, traders, and wholesalers across India. These channels ensure you receive quality-assured products for your RF network needs.
Q: What is the benefit of using a brass connector for RF applications?
A: Brass offers excellent conductivity and corrosion resistance, ensuring minimal signal degradation over time. This results in dependable, long-lasting connections crucial for consistent RF performance.
Q: How much does the BNC M RG 11 Crimp Connector weigh, and does this impact installation?
A: Each connector weighs only 10 grams, making it lightweight and easy to handle during installation. Its compact design allows for straightforward integration into a variety of RF setups without adding unnecessary bulk.
Q: What process should be followed to achieve optimal crimping results?
A: To achieve the best results, use a calibrated crimping tool designed for RG 11 cables. Strip the cable to the specified dimensions, insert it into the connector, and crimp firmly to ensure a strong mechanical and electrical bond.
