Broadband RF Power Amplifier 1-1000MHz
Product Details:
- Interface Type SMA Female Connectors
- Power Supply +12V DC, 2A
- Features Wide frequency range, high linearity, low noise, compact design
- Range 1 MHz to 1000 MHz
- Connectivity Type RF input/output connectors (SMA type)
- Operating Temperature -20°C to +60°C
- Model BPA-1-1000
- Click to View more
X
Broadband RF Power Amplifier 1-1000MHz Price And Quantity
- 1 Piece
Broadband RF Power Amplifier 1-1000MHz Product Specifications
- SMA Female Connectors
- 10W (Output power)
- +12V DC, 2A
- Wide frequency range, high linearity, low noise, compact design
- 1 MHz to 1000 MHz
- Dependent on system integration, typically used for general RF labs and systems
- RF input/output connectors (SMA type)
- -20°C to +60°C
- Broadband RF Power Amplifier
- BPA-1-1000
- No built-in battery backup
- Aluminum Alloy Enclosure
- Broadband signal amplification, RF communication systems, lab testing, wireless infrastructure
- Panel or surface mount
- 110 mm x 63 mm x 22 mm
- 1 - 1000 MHz
- Approx. 350g
- Standard Compact
- Silver (Anodized)
- 48 dBm
- -20 dBc
- +12V DC (regulated required)
- 40 dB (typical)
- Better than 12 dB
- 50 Ohm
- 1.5 dB
- -40C to +85C
- 39 dBm (10W)
- <5 dB
- SMA Female (Input & Output)
- Natural Convection, Heat Sink Provided
- Better than 12 dB
Broadband RF Power Amplifier 1-1000MHz Trade Information
- Cash Advance (CA), Cash in Advance (CID)
- 100 Piece Per Month
- 4 Week
- 40*25*25
- Asia
- All India
- ROHS
Product Description
10 -100W (40 - 50dBm) Variable Power Output
RF Power Amplifier can be customized and Lab certified for any frequency band as per requirements.
We Synergy Telecom Pvt Ltd have deals in all type product supply of RF And T & M Analyzers/site Master/VNA/ Signal Generator / Calibration kits and all type of test adapters .We are doing different types of Antenna, Jumper, RF cables, Attenuator, Dummy loads, DC block, Splitter, Duplexer, Couplers, Combiners, RF connector, RF Co-axial Cable, TELECOM tools, GPRS, RFID product supply to corporate, Educational Institutions, government, Engineering and defense sector. If you have any requirement then please let use know. Synergy Telecom P Ltd.
Advanced Performance Across Wide Frequencies
Operating seamlessly between 1 and 1000 MHz, this amplifier delivers a consistent 10W output while maintaining industry-leading standards in linearity and noise. Its high OIP3 and low harmonics ensure signal purity, supporting critical applications in labs and communication systems alike.
Efficient Cooling and Durable Build
The BPA-1-1000 utilizes natural convection with an included heat sink, facilitating reliable, silent operation even under demanding duties. The compact, anodized aluminum alloy enclosure adds to its durability, making it suitable for rigorous use in varied environments.
Seamless System Integration
Equipped with SMA female connectors and standard panel or surface mounting options, integration into RF test setups or existing communication infrastructure is effortless. Its regulated +12V DC supply requirement and wide storage temperature range enhance compatibility and deployment flexibility.
FAQs of Broadband RF Power Amplifier 1-1000MHz:
Q: How can the BPA-1-1000 amplifier be integrated into an RF communication system?
A: The BPA-1-1000 features SMA female connectors for both input and output, making it compatible with a wide range of RF cables and devices. Its panel and surface mounting support allows for flexible installation in racks or enclosures within communication systems or lab setups.Q: What is the typical process for powering and operating this RF amplifier?
A: To operate the amplifier, connect a regulated +12V DC (2A) power supply to the device. Ensure secure RF connections via SMA interfaces, and maintain sufficient airflow around the attached heat sink for optimal natural convection cooling during use.Q: When is this amplifier most beneficial for use in laboratory and wireless infrastructure?
A: The BPA-1-1000 is especially advantageous in scenarios requiring consistent broadband signal amplification, including RF testing, prototyping, and wireless communication systems that demand a wide frequency range, high gain stability, and low noise characteristics.Q: Where is the BPA-1-1000 typically installed or deployed?
A: This amplifier is commonly installed in RF labs, communication system chassis, and wireless infrastructure hubs. Its compact dimensions (110 mm x 63 mm x 22 mm) and standard mounting options support adaptation to different operational environments.Q: What are the primary benefits of choosing this amplifier over similar products?
A: Key advantages include wide 11000 MHz frequency coverage, superior 40 dB gain, low noise, high linearity, and durability provided by the anodized aluminum enclosure. These features ensure reliable, distortion-free performance suitable for both commercial and research applications.Q: How does the cooling method enhance the amplifiers reliability?
A: The amplifier utilizes a heat sink and natural convection for thermal management, eliminating the need for noisy or failure-prone fans. This approach extends device longevity and ensures consistent operation across the specified temperature range.Tell us about your requirement
