Product Description
Electrical
Characteristic Impedance 50 ohm
Frequency Range DC75GHz
VSWR 110DC3000MHz
Dielectric Withstanding Voltage 4000V RMS,50Hz,at sea level
Dielectric Resistance 10000M Contact
Resistance Center Contact 04m
Outer Contact 1 m
Engineered for High-Performance RF ApplicationsSpecifically crafted for use with LMR 400 cables, this DIN Male Crimp Connector delivers dependable signal transfer in RF and microwave systems. Its single-conductor design guarantees low attenuation and is suitable for both commercial and industrial settings where secure and efficient connections are essential.
Rugged Construction for Diverse EnvironmentsManufactured from quality brass materials and finished in silver, the connector is built to withstand harsh indoor and outdoor conditions. The sturdy 100-gram construction not only provides durability but also helps ensure a stable and interference-free connection in challenging environments.
FAQs of DIN Male FOR LMR 400 CRIMP CONNECTOR:
Q: How is the DIN Male for LMR 400 Crimp Connector installed on a cable?
A: Installation requires a proper crimping tool matched to the LMR 400 cable. Strip the cable insulation, insert the conductor into the connector, and crimp it securely using the appropriate die set. Detailed instructions are recommended for optimal performance.
Q: What makes this connector suitable for both indoor and outdoor use?
A: The connectors brass construction and robust silver finish provide excellent resistance to environmental factors, making it reliable for installations in both controlled indoor settings and exposed outdoor areas.
Q: Where can this connector be used in RF and microwave applications?
A: It is suitable for use in RF cable assemblies, antenna connections, telecommunications, and microwave equipment, where secure signal transmission and minimal loss are necessary.
Q: What are the main benefits of using a crimp connector over other types?
A: Crimp connectors offer superior mechanical stability, lower signal loss, and easier installation for high-frequency applications compared to soldered or screw-on connectors.
Q: What is the weight and size of this connector, and why does it matter?
A: The connector weighs 100 grams and is specifically sized for LMR 400 cables, providing a secure and balanced fit that prevents signal degradation and ensures mechanical integrity.
Q: Can this connector handle high power and voltage applications?
A: It supports up to 50 Watts of power, making it suitable for moderate-power RF applications. Ensure your specific voltage requirements are compatible before installation.
Q: What is the primary usage of this DIN Male Crimp Connector?
A: It is mainly used as a connector for cable and microwave parts, enabling consistent and reliable RF signal transmission in professional and industrial environments.
