Solar Branch Solar Connector

Solar Branch Solar Connector

Product Details:

  • Product Type solar product
  • Application connector
  • Supply Ability : 1000 Pair Per Week
X

Price And Quantity

  • 210.00 - 230.00 INR
  • 1 Pair
  • 210 INR

Product Specifications

  • solar product
  • connector

Trade Information

  • Delhi
  • Cash in Advance (CID), Telegraphic Transfer (T/T)
  • 1000 Pair Per Week
  • 1 Week
  • customized pkg
  • Middle East, Eastern Europe, South America, North America, Central America, Australia, Asia

Product Description

Solar Branch Solar Connector
  • MODEL NO.       RO-2
  • Rated Voltage: 1500V
  • Rated Current:  30A
  • Rated Impulse Voltage:  1600V
  • Rated Test Voltage: 6KV(50Hz,1Min)
  • RMS Withstand Voltage:  8000V
  • Contact Resistance: 0.3m
  • Conductor Tin plating: copper
  • Operating Temperature:  -40~+85
  • Max. Operating Temperature: 100
  • Degree of Protection: IP67
  • Fire Protection Class: UL94-V0
  • Application Class: Class A
  • Safety Class:  Class II
  • Pollution Degree:  I
  • Overvoltage: Category I
  • Flame Class:  UL94-V0
  • Conductor Cross Section: 2.5~10.0mm
  • Specify outer wire: dia. 2.5~6.0mm2 AWG14/12/8
  • Insulation Material: Polycarbonate (PC)
