UHF F 4 HOLE SOLDER CONNECTOR
60 INR/Piece
Product Details:
- Product Type UHF CONNECTOR
- Material BRASS
- Usage RF Network & RF Cable Assemblies
- Application RF Equipment & IBS - BTS
- Power 50 Ohm (ohm)
- Voltage 50 Watt (w)
- Weight 10 Grams (g)
- Click to View more
X
UHF F 4 HOLE SOLDER CONNECTOR Price And Quantity
- 60 INR/Piece
- 10 Piece
UHF F 4 HOLE SOLDER CONNECTOR Product Specifications
- UHF CONNECTOR
- 10 Grams (g)
- RF Equipment & IBS - BTS
- BRASS
- 50 Ohm (ohm)
- RF Network & RF Cable Assemblies
- 50 Watt (w)
UHF F 4 HOLE SOLDER CONNECTOR Trade Information
- New Delhi
- Paypal, Telegraphic Transfer (T/T), Cash in Advance (CID), Cheque
- 5000 Piece Per Day
- 1-2 Days
- Yes
- Free samples available with shipping and taxes paid by the buyer
- As Required Buyer
- Africa, Central America, Eastern Europe, Middle East, South America, Western Europe, Asia, North America, Australia
- All India
Product Description
Electrical:
Characteristic Impedance 50 ohm
Frequency Range DC-4 GHz
VSWR 1.15@DC-3 GHz
Dielectric Withstanding Voltage 1000V RMS,50Hz,at sea level
Dielectric Resistance 5000M
Contact Resistance Center Contact 1m
Outer Contact 0.25m
Precision Engineering for RF Applications
Engineered with a focus on RF equipment requirements, the UHF F 4 Hole Solder Connector offers enhanced signal integrity and lasting durability. Its brass construction and four-hole mounting design enable stable installation and minimal signal loss, making it suitable for critical wireless setups such as IBS and BTS.
Versatile and Reliable Connectivity
Supporting applications in RF network and cable assemblies, this connector operates efficiently at 50 watts and 50 ohms, ensuring compatibility with a wide range of RF devices. Its lightweight 10-gram build allows for easy handling and integration, whether in professional installations or maintenance activities.
FAQs of UHF F 4 HOLE SOLDER CONNECTOR:
Q: How is the UHF F 4 Hole Solder Connector installed in RF cable assemblies?
A: The connector is mounted using its four-hole flange, which allows secure attachment to panels or equipment. The solder-type connection ensures strong electrical contact with the cable, making it suitable for use in professional RF cable assemblies.Q: What applications benefit from using this brass UHF connector?
A: This connector is ideal for RF equipment and infrastructure, particularly in IBS (In-Building Solutions) and BTS (Base Transceiver Stations), due to its robust design, reliable connection, and compatibility with RF network setups.Q: When should I choose a UHF F 4 Hole Solder Connector over other types?
A: Select this connector when you require secure panel mounting, reliable signal transmission at 50 ohms, and a robust brass structure that accommodates up to 50 watts for demanding RF environments.Q: Where can I source this connector in India?
A: The UHF F 4 Hole Solder Connector is available through various distributors, manufacturers, suppliers, traders, and wholesalers across India, ensuring accessibility for projects and resellers nationwide.Q: What is the process for integrating this connector into existing RF networks?
A: To integrate, solder the connector to the compatible cable, mount it securely using the four-hole flange to the designated panel, and ensure all electrical connections match your networks power and impedance requirements for optimal system performance.Q: What are the primary benefits of choosing a brass UHF connector?
A: Brass offers excellent conductivity and corrosion resistance, ensuring dependable signal transmission and durability in harsh RF environments. The connectors design also enables straightforward installation and long-term reliability.Q: How does the 50-ohm, 50-watt rating impact connector performance?
A: The 50-ohm impedance ensures compatibility with most RF systems, minimizing signal loss, while the 50-watt power rating supports moderate to high power transmission without risk of overheating, delivering efficient operation in network applications.Tell us about your requirement
